- feature : Touch Screen
- Brand : Neutral
- place of origin : Guangdong, China
- camera : No Camera
- Control Method : Touch
- design : SLIDER
- display type : TFT
- Operation System : Android
- private mold : Yes
- Product Type : Smart Home Control Panel
- screen : ≥5.0″
- screen resolution : 1920X1080
- use : Universal
- Product name : 10 inch KNX Smart Touch Panel
- Product model : S9KE
- Function : KNX System Control
- Network : Wi-Fi 2.4&5GHz/ Ethernet
- Power supply : 24V DC POE Optional
- System : Android 11
- Working Temperature : 0℃~40℃
- Working Humidity : ≤90% RH
- Material : PC
- Dimentions : 272X155X38mm with back base
2024 Newest Big 10 inch KNX Smart Touch Panel for Smart Home Building Management System Support 20 Scenes 150 Devices Touchscreen
Products Description
|
Product Name
|
10 inch KNX Touch Panel
|
|
Model Name
|
S9KE
|
|
Function
|
Whole Home Automation Control
|
|
Package
|
Neutral
|
|
Power supply
|
24V DC（24V-30V）POE Optional
|
|
Wireless Protocols
|
KNX
|
|
Working Temperature
|
0℃ to +40℃
|
|
Working Humidity
|
5% to 90% RHNon-condensing
|
|
Net weight
|
176g
|
|
Product dimensions
|
272X155X11.5mm Without back base
272X155X38mm with back base |
|
Back base
|
Fits in ALL standard wall box
|
|
Specification
|
|||
|
CPU
|
RK3566 Quad-core Cortex-A55
|
OS
|
Android 11
|
|
RAM
|
2G，LPDDR4
|
Screen
|
10 inch 1920*1200
|
|
ROM
|
16G，eMMC
|
Bluetooth
|
BT 5.2
|
|
Ethernet
|
RJ45, 100M network, POE Optional
|
Sensor
|
Radar distance sensor, light sensor, temperature&humidity sensor
|
|
WIFI
|
2.4&5GHz，802.11a/b/g/n/ac/ax
|
Material
|
PC
|
|
Support Scenes
|
20
|
Support Devices
|
150
|
KNX 10 inch Smart Touch Panel
● 10.1-inch LCD, 1920*1200, with 4 buttons.
● Built in Radar distance sensor, light sensor, temperature&humidity sensor.
● Multi-page, room devices display and control
● Support 20 scenes and 52 devices.
● Password function, screen-saver, and panel lock function.
4 Cooperation Options for You:
Cooperation ①: Tuya Zigbee gateway panels.
Cooperation ②: Open Android panels for installing the customer’s App, firmware, and modules. PoE Optional
Cooperation ④: Customize a new product according to your needs.
Cooperation ③: KNX series panels.
Cooperation ④: Customize a new product according to your needs.
Recommend Products
Best Selling
Company Profile
Smatek Electronics Limited, was established on June 1, 2012. Its main business is to provide customers with a series of smart control panel solutions such as smart home appliances, medical, home, industrial control, etc. based on embedded platforms such as Android/Linux/Rtos.In recent years, with the development of smart home system and related industries, the company has increased its investment in scientific research and fully integrated artificial intelligence technologies such as 5G, I0T, and voice interaction to create new smart home products and smart home innovation systems based on the central control panel. It has been successfully applied to domestic smart homes, smart hotels, smart office projects, smart education, smart real estate, smart security, smart lighting, etc. The company has also become a leader in domestic smart home industry solution providers and has successfully provided solution services for many leading brands in the industry.We adhere to the tenets of stability, reliability, professionalism and focus, take creating value for customers as our mission, and are committed to becoming an industry-leading intelligent system solution provider.The systems used in the solution include:Android, Linux and Rtos systems, covering the needs of high-performance large-screen solutions and cost-effective small-screen solutions for smart home central control products.Supports multiple communication modes of device access including:Zigbee, WiFi, KNX, Bluetooth Mesh RS485, PLC, etc.For OEM/ODM services, welcome to contact us at any time!
FAQ
Q1: Do you accept OEM & ODM?
A1: Yes, we accept. OEM/ODM is what we are good at and it is our advantage. We support custom Zigbee, Boot Animation, Logo, App, etc. For more details, contact us now. We can quickly respond to your need at any time!
A1: Yes, we accept. OEM/ODM is what we are good at and it is our advantage. We support custom Zigbee, Boot Animation, Logo, App, etc. For more details, contact us now. We can quickly respond to your need at any time!
Q2: I don’t know the product clearly, how can I install it?
A2: We have the product’s user manual and can send you a video if you need it. Or you can contact us, we’d love to help. So you don’t have to worry about installation.
Q3: How to ensure the quality of the product?
A3: We take a rigorous process that includes thorough testing for functionality, reliability, compatibility, aging test with
devices, robust security measures, and always final Inspection before shipment. If you have any quality issues in using our
product, feel free to contact us at anytime.
Q4: How long is the delivery time?
A4: Normally within 5 working days for sample orders when in stock, bulk order time depends on the quantity.
| color | KNX S9KE, POE S9PE, Tuya S9E |
|---|---|
| model number | S9KE, S9PE, S9E |
| plug type | UK, EU, US, Asian |
